Limited Edition Tamiya 47497 Squash Van 1/10 - Green/White Pre-Painted Body with GF-02 Chassis and ESC  [47497]

Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC
Price:
£151.37
Brand:
Tamiya
Model:
47497
GTIN:
4950344474974
Condition:
Brand New
Available in warehouse
Write a review
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"
alt="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC" title="Tamiya 47497 - 1/10 RC Squash Van (Green/White Painted Body) (GF-02 Chassis) w/ESC"

Classic 1950s styling with a modern GF-02 base

The Tamiya Squash Van 47497 recreates the character of mid-century American panel vans while using contemporary RC components. The Cobalt Green polycarbonate body with white roof is supplied pre-painted and fits the gear-driven GF-02 chassis, offering a pleasing blend of period looks and everyday usability.

Chassis design and driving characteristics

The GF-02 chassis emphasises believable wheelbase proportions and sturdy layout, distinguishing it from smaller platforms like the GF-01. Its ladder and pipe visual cues reflect scale realism, and the combination of 4WD and fully independent double wishbone suspension delivers composed, controllable behaviour on a range of driving surfaces.

Accessible kit for beginners, flexible for tinkerers

The pre-cut body mounts and painted shell make initial assembly straightforward, so newcomers can get rolling quickly. Enthusiasts will find room for upgrades and tuning. The kit includes a 540 brushed motor and ESC; to complete the model you will need a 2-channel radio, steering servo and appropriate battery and charger.

Specifications

  • Scale: 1/10
  • Wheelbase: 267 mm
  • Tread (Front/Rear): 223mm / 221mm
  • Tires: V-Block pattern, 122.8mm diameter
  • Gear Ratios: 18T (18.03:1), 20T (16.23:1), 17T (19.09:1)
  • Motor: 540 brushed type
  • Chassis Type: GF-02
  • Suspension: Fully Independent Double Wishbone
  • Drive Type: 4WD

The Tamiya Squash Van 47497 pairs nostalgic bodywork with a reliable GF-02 underpinnings, making it a strong choice for collectors and drivers who want a distinctive, tuneable 1/10 scale model.

Yes, standard size steering servos fit the mounting points. For tighter steering response, consider a high-torque metal-geared servo.
Absolutely. The detailed pre-painted body makes it an attractive display piece, while the GF-02 chassis keeps it fully drivable for shows and demos.
Verify servo centring and endpoints, ensure the battery is secure and charged, check gear mesh on the pinion and spur, and confirm the tyres are fitted and inflated if applicable.
Yes, four-wheel steering can be added with additional servos and the correct radio programming. Ensure you plan servo placement and linkage geometry before modification.
