Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957  [53957]

Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957
Price:
£236.61
Brand:
Tamiya
Model:
53957
GTIN:
4950344539574
Condition:
Brand New
Write a review
alt="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957" title="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957"
alt="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957" title="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957"
alt="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957" title="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957"
alt="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957" title="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957"
alt="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957" title="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957"
alt="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957" title="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957"
alt="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957" title="Tamiya 53957 - RC Multi-Function Control Unit - Pick-Up Truck (MFC-02) OP-957"

Released in 2006, the 1/10 R/C 4x4 3-Speed High-Lift had been incredibly well-received by fans across the world. Along with the release of this groundbreaking Multi-Function device, Tamiya kicks up the realism another notch with light, sound, and vibration impacts all controllable via a 4-channel transmitter (offered separately) to create all 3-Speed Highlifts more impressive!!!

LIGHT EFFECTS

10 kinds of high-brightness LEDs (including optional LEDs) for a complete all the way to 33 lights are was able to depict different practical light actions while driving. They might additionally light in pre-set habits during Demo Mode for an excellent rack display.

Headlight 1 Headlight 2 High Beam
Fog Lamp 1 Fog Lamp 2 Fog Lamp 3
Fog Lamp 4 Fog Lamp 5 Auxiliary Lights (Front)
Auxiliary Lights (Backside) Turn Signal (Front Appropriate) Change Signal (Front Kept)
Change Signal (Backside Appropriate) Change Signal (Back Kept) Reverse Lamp
Brake Lamp Flash Lamp

SOUND DATA

Onboard presenter unit can emit an overall total of 24 different sound files (including optional noises) that have been all digitally recorded from genuine automobiles, just like the working noises for both a sizable imposing V8 engine and a spunky small-displacement turbo motor.

engine Creating 1 Idling 1 Running 1
Engine Stop 1 Up-shifting 1 Down-shifting 1
Horn 1 Engine Opening 2 Idling 2
Running 2 motor avoid 2 Up-shifting 2
Down-shifting 2 Horn 2 Gear Changing
Turn Signal Timer 1 Timer 2
Timer 3 security

SPECIAL OPERATIONS as much as 16 different actions are controlled via a 4-channel transmitter (offered individually) to offer the feeling of driving an actual pick-up truck.

Steering ControlThrottle ControlHorn Operation
Tall Beam ProcedureGear Moving OperationTurn Signal Operation
Hazard Lamp ProcedureHeadlight OperationBrake Operation
Motor Start/Stop Operation

MORE QUALITIES

  • Vibration Function device recreates rumble motions along with motor noises.
  • ESC allows practical low-speed running.
  • Speaker unit not simply emits the noise files stated earlier, it offers an input terminal to enable experience of outside audio sources such as for example MP3 and CD players for music playback.
  • 3 convenient modes of procedure: R/C mode with Multi-Function outcomes down, R/C mode with Multi-Function effects on (4 varieties), and Demo Mode for static display with light and noise results simply (4 varieties).
  • Detail by detail and user-friendly set-up guide and tutorials to help users with appropriate procedure on most the MFC-02 features (please begin to start to see the next web page for some initial sample diagrams).

SEPARATELY FORCED ITEMS

  • 4-channel self-neutral stick-type transmitter constructed with fall trim and self-neutral function for optimum performance. (Futaba Attack 4WD recommended)
    Tamiya recommends the Futaba Attack 4WD (T4VWD/FP-R114H) because it has a self- neutral function. Other 4-channel transmitters made by Futaba, JR Propo, and Acoms may be used using the MFC-02, but operations may possibly not be since smooth since they may lack the self-neutral feature and connectors might not be appropriate. For transmitters off their manufacturers, whilst it could be feasible to use them, be sure to know that there may be circumstances where they are able to never ever manage to operate every one of the MFC-02's functions.
  • 4-channel receiver.
  • 2 servos.

SPECIAL RECORDS

  • avoid and ITEM# 53909 TLU-01 or ITEM# 53937 TLU-02.
  • MFC-02 works with with the Type 540 engine only. Please avoid installing other machines.
  • MFC-02 cannot be operated with 2-channel or 3-channel transmitters/receivers.
  • MFC-02 is not appropriate PCM type receivers, multi-channel receivers, and older receivers developed by Sanwa (identifiable by their black colored instances).
  • Maybe not Compatible with 2.4ghz systems or others which have electronic trim
