HOBBYWING QuicRun 3650SD 25.5T G2 Brushless Motor 30404308 - Precision Sensored Motor  [HW-30404308]

HOBBYWING QuicRun-3650SD-25.5T G2 - 30404308
Price:
£42.71
Brand:
Hobbywing
Model:
HW-30404308
Condition:
Brand New
Write a review
alt="HOBBYWING QuicRun-3650SD-25.5T G2 - 30404308" title="HOBBYWING QuicRun-3650SD-25.5T G2 - 30404308"
alt="HOBBYWING QuicRun-3650SD-25.5T G2 - 30404308" title="HOBBYWING QuicRun-3650SD-25.5T G2 - 30404308"
alt="HOBBYWING QuicRun-3650SD-25.5T G2 - 30404308" title="HOBBYWING QuicRun-3650SD-25.5T G2 - 30404308"
alt="HOBBYWING QuicRun-3650SD-25.5T G2 - 30404308" title="HOBBYWING QuicRun-3650SD-25.5T G2 - 30404308"

HOBBYWING 30404308 Motor Summary

The HOBBYWING 30404308 is aimed at drivers who want steady, manageable power for small-scale racing and practice. Its combination of torque and RPM makes it versatile across different RC applications.

Sensored Performance Insights

The sensored arrangement helps eliminate jerky starts and improves throttle fidelity, which is useful for consistent lap times and controlled corner exits on slippery tracks.

Fitment and Power Options

At 1520 KV and compatible with 2-3S LiPo packs, the motor works with 1/10th touring cars, 1/12th F1 types and compact off-road cars. Dimensions and weight are in line with standard chassis expectations.

Practical Racing Features

Fixed timing and a two-pole design prioritise efficiency and stable output for stock and sports classes, helping drivers maintain predictable performance through heats and practice sessions.

Specifications

  • Scale: 1/10 and 1/12
  • Type: Brushed/Brushless, Sensored
  • KV Rating: 1520
  • Compatible LiPo Cells: 2-3S
  • No-load Current: 1.1A
  • Outer Diameter: 36mm
  • Length: 52.8mm
  • Shaft Diameter: 3.17mm
  • Weight: 186g
  • Timing: Fixed

For modelers seeking a reliable sensored brushless motor that spans multiple small-scale classes, the HOBBYWING 30404308 offers a sensible balance of control and performance.

Yes, the physical dimensions and shaft size are compatible with common 1/10 motor mounts, but always check clearance for your specific chassis and pinion selection.
Maintenance is similar to other brushless motors: monitor bearings, keep the sensor connector secure and avoid debris ingress to sustain reliable sensor readings.
The 30404308 fits well in stock and sport-style classes where regulated performance and consistency are important, thanks to its fixed timing and efficient configuration.
Select a conservative pinion to start and tune up for more top speed if temperature and handling remain within safe limits. Monitor motor temperature during tuning runs.
