Hobbywing 30401061 XERUN-3652SD 6100KV Performance Motor  [HW-30401061]

HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061
Price:
£0.00
Brand:
Hobbywing
Model:
HW-30401061
Please kindly input your name and email address, we will inform you once we have the restocking.
Or you may find similar product under the
category
Write a review
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"
alt="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061" title="HOBBYWING XERUN-3652SD-6100KV-D5.0-G2 - 30401061"

Performance-Focused Hobbywing XERUN-3652SD for 1/10 Scale

The Hobbywing XERUN-3652SD-6100KV-D5.0-G2 is aimed at model racers who want a sensored brushless option for 1/10 scale cars. Its 6100KV rating supports high speed while maintaining usable throttle control for cornering.

Consistent Output with 4-Pole Construction

The 4-pole design ensures steady torque delivery and reliable midrange response that helps drivers hit consistent lap times. The motor records a no-load current of 5.9A and an internal resistance around 2.9 mOhm for efficient operation.

Timing Adjustment to Suit Racing Conditions

Adjustable timing between 20 and 40 degrees allows you to tune for traction and gearing preferences, giving the option to favour acceleration or maximum velocity depending on the circuit.

Specifications

  • KV Rating: 6100
  • LiPo Cells: 2S
  • No-load Current: 5.9A
  • Resistance: 2.9mΩ
  • Outer Diameter: 36mm (1.417in)
  • Length: 52.5mm (2.067in)
  • Shaft Diameter: 5mm (0.197in)
  • Weight: 186g (6.56oz)
  • Shaft Length: 15mm (0.591in)
  • Timing: 20-40 Degrees (Adjustable)

Ideal for racers chasing precise setup control, the Hobbywing XERUN-3652SD adds reliable high-speed capability and clear tuning options to 1/10 scale race cars.

Yes, its 6100KV and sensored operation suit touring car setups where controllable power delivery and smooth throttle response are important.
Use conservative gearing, monitor motor and ESC temperatures, and allow cooling runs between hard sessions. Proper ventilation in the motor bay helps reduce thermal buildup.
Yes, increasing timing and adjusting gearing can improve acceleration, but be mindful of increased current draw and heat as you tune for more punch.
Regularly inspect bearings and motor mount screws, keep the endbell clean, and check that wires and connectors are secure to maintain long term reliability.
