Optimise Throttle Control with the XERUN 3660SD

The Hobbywing XERUN 3660SD-4300KV-D5.0-G2 is targeted at drivers who want predictable power delivery and fine control. Its sensored brushless design improves low-speed handling and makes throttle application more consistent.

Engineered 4-Pole for Even Power

The 4-pole configuration smooths torque and improves midrange response. With a 4300KV rating the motor offers brisk acceleration, and the 20 to 40 degree adjustable timing lets you tune spool and peak power to match track demands.

Robust Dimensions and Easy Gearing

Built to cope with demanding use, the XERUN 3660SD measures 36mm diameter by 62mm length and weighs 218 grams. The 5mm shaft is compatible with standard pinions for straightforward gearing swaps.

Specifications

  • Type: Brushless, Sensored
  • KV Rating: 4300
  • LiPo Cells: 2S
  • No-load Current: 4.7A
  • Resistance: 3.8mΩ
  • Outer Diameter: 36mm
  • Length: 62mm
  • Shaft Diameter: 5mm
  • Weight: 218g
  • Shaft Length: 17mm
  • Timing: 20-40 Degrees (Adjustable)

A practical choice for racers and hobbyists, this motor combines adjustable timing and a high KV for tunable performance across a range of 1/10 scale vehicles.

You should use an ESC that supports sensored motor inputs to take full advantage of the XERUN 3660SD. Check the ESC manual for sensor wiring and compatibility notes.
Yes, increasing timing typically raises RPM and current draw which can increase motor temperature. Make changes incrementally and monitor temps on short runs.
Upgrading to quality bearings and ensuring proper ventilation in your chassis can extend motor life. Regular cleaning and checking shaft runout will also help reliability.
